Four Segment Shield Anchor

Get a Price/Quote

MOQ : As per requirement Piece

Four Segment Shield Anchor Specification

Thickness
Variable (Depends on required anchor size, typically 2.5 mm to 5 mm)

Surface Treatment
Zinc plated, Yellow passivated

Dimension (L*W*H)
Based on diameter and length required (e.g., 10x60 mm, 12x75 mm)

Diameter
8 mm, 10 mm, 12 mm, 16 mm, 20 mm (available in various sizes)

Head Type
Hex bolt / Flat head bolt (as per requirement)

Length
50 mm, 60 mm, 75 mm, 100 mm, 120 mm (available in various sizes)

Heat Treatment
Case hardened

Thread Type
Metric external thread

Standard
IS 1367 / DIN 446

Grade
Mild steel or carbon steel

Use
For securing heavy-duty fixings to concrete, brick, and stone

Applications
Suitable for heavy machinery, structural steelwork, safety barriers

Corrosion Resistance
High, due to surface plating

Packaging
Box/Carton packing as per size and order quantity

Number of Segments
4 (four-segment expanding shield design)

Installation Method
Through hole installation, expands on tightening

Material
Steel

Anchor Type
Mechanical expansion anchor

Pull-Out Strength
High holding power in solid base materials

Finishing
Electro-galvanized, Hot dip galvanized

Four Segment Shield Anchor Trade Information

Payment Terms
Cash in Advance (CID), Cheque, Cash Advance (CA)

Delivery Time
as per order Week

Sample Available
Yes

Main Export Market(s)
Australia, Central America, South America, Eastern Europe, Western Europe, Middle East, Africa, Asia, North America

Main Domestic Market
All India

About Four Segment Shield Anchor

We are well known manufacturer and supplier of Four Segment Shield Anchor Bolt in the market. These anchor bolts are fabricated with high quality of raw materials and components which result in its reliability, high performance and durability at customers end.Four Segment Shield Anchor Bolts are highly preferred at concrete place to fasten where surface is hard and even. Its use is easy and quick, while fastening the nut or screw the conical part is pulled into the anchor shells expanding it.

Advanced Four-Segment Expanding Shield Design

Engineered with four expansion segments, the anchor achieves exceptional grip in solid base materials. The shields mechanical expansion ensures a strong, stable hold, minimizing the risk of loosening under heavy loads or vibrations. This innovative design makes it dependable for critical applications in construction and heavy industry.

Premium Materials and Superior Corrosion Resistance

Crafted from grade mild steel or carbon steel, these anchors undergo advanced surface treatments, including electro-galvanizing and hot-dip galvanizing, to enhance rust protection. These finishes, along with zinc plating or yellow passivation, enable use in demanding environments where long-lasting performance is essential.

Versatile Applications and Customizable Specifications

Available in multiple diameters (8 mm to 20 mm) and lengths (50 mm to 120 mm), these anchors accommodate various bolt head types and thread sizes. They are ideal for securely fastening heavy machines, safety barriers, and steel structures, especially where strength and reliability are paramount.

FAQs of Four Segment Shield Anchor:

Q: How is the Four Segment Shield Anchor installed for maximum holding power?

A: The anchor is installed using a through-hole method. First, drill a hole in the base material to the appropriate size and depth, insert the anchor, and then tighten the bolt. As you tighten, the four-segment shield expands outward, securely locking the anchor in place for high pull-out strength.

Q: What types of applications is this anchor most suitable for?

A: This anchor is ideally used for securing heavy-duty fixings such as heavy machinery, structural steelwork, and safety barriers. It is suitable for installations in concrete, brick, and stone where reliable load-bearing and safety are critical.

Q: Where can Four Segment Shield Anchors be used effectively?

A: They are most effective in solid base materials including concrete, brick, and natural stone. Common settings include construction sites, industrial facilities, and infrastructure projects requiring heavy-duty, corrosion-resistant anchoring solutions.

Q: What benefits does the four-segment expanding shield design offer?

A: The four-segment design allows even expansion, which increases grip and maximizes holding capacity. This ensures better load distribution, minimizes slippage, and increases durability in high-stress conditions.

Q: When should you opt for electro-galvanized or hot-dip galvanized finishes?

A: Choose electro-galvanized anchors for indoor or mildly corrosive environments, and hot-dip galvanized for outdoor or highly corrosive settings. Both treatments significantly enhance corrosion resistance and prolong anchor lifespan.

Q: What is the process for choosing the correct size and specification?

A: Determine the required diameter and length based on the thickness and type of materials to be fastened. Ensure compatibility with site standards (IS 1367/DIN 446), and select the appropriate finish depending on the required corrosion resistance and application conditions.

Q: How does surface treatment improve the anchors performance?

A: Surface treatments such as zinc plating and yellow passivation create a protective layer on the steel, preventing rust and corrosion. This ensures reliable performance and longevity, even in harsh or exposed installations.
